Wood kiln drying machine/ high frequency vacuum wood dryer

FOB Reference Price:Get Latest Price
US $35,000-40,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Vacuum Drying Equipment
Place of Origin:
Hebei, China (Mainland)
Brand Name:
DX
Model Number:
DX-3.0III-DX
Voltage:
380v
Power(W):
10kw
Dimension(L*W*H):
4400*1716*1806MM
Weight:
4000KGS
Certification:
CE ISO
Warranty:
1Year
After-sales Service Provided:
Engineers available to service machinery overseas
vacuum oven:
3-10cbm
Out Dimension:
4400*1716*1806
inside Dimension:
3600*1500*1500
timber cart:
3000*1100*1000
max lenght of wood:
3M
high frequency:
6.78MHz
input power:
15KVA
oscillation power:
10KW
weight:
4000
packing:
20GP
Supply Ability
Supply Ability:
7 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard export packing, plastic and foam, fixed by wood pallet, shipped in container by sea
Port
Tianjin,China
Lead Time :
30working days

Wood Drying Chamber ,Woodworking Machinery, HF Vacuum Wood Dry Kiln



Product Description

High vacuum timber dryer adopts high frequency drying, inside and outside of wood timber is heated at same time, uniform heating, high speed drying, short time and good quality, which can keep the timber nature color, meanwhile, the timber is aerated under the vacuum environment, non-cracking, especially applied for the thick and hard precious wood, wet wood.

19

Specification

HF machine power

Effective volume

Wood species

Wood maximum length

Shape dimension

(mm)

Inner space

(mm)

Timber cart

(mm)

3cbm

10KW

3.3m³

All wood

3M

4330

*1716

*1806

3600

*1500

*1500

3000

1100

1000

4cbm

10KW

4.4m³

4M

5330

*1716

*1806

4600

*1500

*1500

4000

1100

1000

6cbm

20KW

6m³

5M

6465

*1916

*2006

5600

*1700

*1700

5000

1200

1000

8cbm

30KW

7.8m³

6M

7605

*2016

*2006

6600

*1700

*1700

6000

1200

1100

10cbm

50KW

10.8m³



7500

2140

2240

6600

*1900

*1900

6000

1500

1200



 1114

Advantages

Quick heating

    It does not require heat conduction, inside and outside of wood timber is heated at same

time.

Fast dehydration



    During the heating process, there is staged temperature difference between inside and

outside of wood timber, this will speed up the water movement from inside wood to outside

wood (the principle is to the convencontrary tional heating).

Good quality of

final wood

    There will be no cracking, bending and color change by taking control of heating speed,

relative vacuum degree & condensing rate.

Strong adaptability

    High frequency vacuum drying can realize not only cold drying but hot drying, help to

eliminate stress, solidify resin.

    This applies to dry all kinds of wood.

High usage

    Square designed drying box supplies more space utilization.

    It is suitable for different shaped wood.

Cost saving

    Fast temperature raise and higher space utilization takes lower cost than traditional ways.

Eco-friendly

    This machine does not pollute the environment.

Full-automatic

    UA Unattended Automatic drying process, very easy to handle.



Detailed Images

This is the core of this machine, all procedures and main technology are inside, including PLC, electric valve etc. Advanced component guarantees customer usage, easy to see and operate.5.png



Double condensation system, to speed up the cooling, to reduce drying time.




Advanced and high strength press system to avoid any bend and crack, and to ensure the drying quality.


Packaging & Shipping

Packing & Delivery:



Packing:  standard export packing with plastic film in one container or as customers' request.

Delivery:   within 30 days after receipt of prepayment



Our engineer will install the machine for the buyers

Instruction Book is inside with the machine.

DSC_0143IMG_20160114_105648IMG_20160114_102643

Honor

.jpg

Our Services

Our service:



1. You can contact me at any time in 24 hours.

 2. We will provide you the technical support .
 3. Fast delivery:we will delivery the goods within 10-15 days after receipt of prepayment
 4. we have professional engineers to serive for you.
 5. Capacity can be customized.
 6. If there is any problems with our products,we will help you to solve the problems as soon as possible.
