hf vacuum small fast drying oven to dry softwood and hardwood

FOB Reference Price:Get Latest Price
$26,000.00 - $28,000.00 / Sets | 1 Set/Sets small fast drying oven (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
GZ-3.0II-DX
Condition:
New
Type:
Drying Oven
Place of Origin:
Hebei, China (Mainland)
Brand Name:
DX
Voltage:
Customized
Power(W):
10 KW
Dimension(L*W*H):
4400*1716*1806MM
Weight:
4000 KG
Certification:
CE/NATIONAL PATENT
Type::
Electric wood dry chamber
Working principle:
High frequency heating and vacuum drying
Control::
Full-automatic
Model::
3,4,6,8,10 cubic meter
Certificate::
ISO 9001:2000
Color::
Could be tailor made as per request
Advantage::
No crackings,color change,rapid heat...
Note::
Special model could be tailor made as per request
Transport::
Could be load by container
Power::
Full Automatic
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 year
Supply Ability
Supply Ability:
7 Set/Sets per Month small fast drying oven
Packaging & Delivery
Packaging Details
plastic and foam packing,fixed by wood pallet, shipped in container by sea
Port
Xingang
Lead Time :
within 20 days



hf vacuum small fast drying oven to dry softwood and hardwood



High Frequency Vacuum Wood Drying Oven is the result of design combining High frequency medium heating technology and Vacuum cryogenic dehydration technology. The working principle of HF medium heating: in the high frequency electrical filed, friction of medium molecule generates heat. Keeping the wood in the frequency electrical filed, thus the inside & outside of wood will be rapidly heating. Meanwhile, vaporizing temperature of water will be decreased under vacuum conditions. Such measures will save energy cost.



DXHF vacuum wood drying equipment adopts high frequency drying, inside and outside of wood timber is heated at same time, uniform heating, high speed drying, short time and good quality, which may keep the timber nature color, meanwhile,the timber is aerated under the vacuum environment, non-cracking, especially applied for the thick and hard precious wood, wet wood.





Please Contact  With Us Today For Details!!!!

  • Quick heating--- It does not require heat conduction,  inside and outside of wood timber is heated at same time;
  • Fast dehydration ---During the heating process, there is staged temprature difference between inside and outside of wood timber this will speed up the water movement from inside wood to outside wood;
  • High quality--- there will be no crackings and color changeby taking control of heatiing speed,relative vacuum degree & condensing rate.
  • Strong adaptability---High frequency-Vacuum drying can realize not only cold drying but hot drying, help to eliminate stress,solidify resin. This applies to dry all kinds of wood
  • High-usage--- Square designed drying box supplies more space utilization. it is suitbale for different shaped wood
  • Cost saving --- Fast tempreture raise and higher sapce utilization takes lower cost than traditional ways.
  • Eco-friendly --- This machine does not pollute the enviroment
  • Full-automatic ---UA UnAttended Automatic drying process,very easy to handle







Specifications of high frequency vacuum wood drying oven:

  1. operating principle: HF medium heating plus vacuum dewatering
  2. Size: 4m*1.76m*1.76m
  3. Weight: 4,000 kgs
  4. Power input: 13 kw
  5. Drying medium: direct heating
  6. Heating mode: electrical medium
  7. Application: drying all kinds of wood
  8. Temperature range: subject to request
  9. Water evaporation: 90kg/24hours (according to follow conditions: high frequency power 10KW, vacuum degree -0.08,condensing temperature 25 °C)
  10. Types: manual, automatic
  11. Models:  12 m3, 15 m33 m3, 4 m3, 6 m3, 8 m3, 10 m3
